Portable Variable Frequency Test System

YF Power's electrical testing equipment is specially designed for field test of 110kV power transformers, GIS, and power cables under 35kV, and it can meet the IEC standard.

1. With module structure designing,  it is very flexible to have serial or parallel connections for meeting kinds of applications.

2. With a compatible design, it is easy to move and load & unload during use.

3. With a friendly operation interface, is easy to operate during working.

zno varistors

Main Components of Portable Variable Frequency Test System

  • Variable frequency converter

  • Excitation transformer

  • HV reactor

  • Voltage divider

  • Remote control system(optional)


System Model Sheet of Portable Variable Frequency Test System

MODELCAPACITYRATING  VOLTAGERATING CURRENTFREQUENCY
SLYFK-160/26160kVA26kV6A30 to 300Hz
SLYFK- 160/2x26160kVA52kV3A30 to 300Hz
SLYFK-320/40320kVA40kV8A30 to 300Hz
SLYFK-320/2x40320kVA80kV4A30 to 300Hz
SLYFK-320/8x40320kVA320kV1A30 to 300Hz
SLYFK-480/26480kVA26kV18A30 to 300Hz
SLYFK-480/2x26480kVA52kV9A30 to 300Hz
SLYFK-480/6x26480kVA156kV3A30 to 300Hz


Please Contact YF Power!
