The product is light in weight, easy and convenient to install on site, and does not need special grounding treatment, and it only needs to meet the natural grounding requirements of the tower.
In case of failure and damage under special circumstances, the overall mechanical and insulation performance of the product will not be damaged, and immediate repair and replacement are not required, but there is no lightning protection function under operating conditions.
Rated voltage | 17kV |
Nominal discharge current | 10kA |
2ms square wave current | 400A |
1mA reference voltage | 25kV |
4/10μs high current impulse | Up to 120kA |
Power frequency humidity tolerance voltage | Not less than 13kV |
